S24110 Datasheet
Download
| Stored energy | 2816Wh |
| Rated capacity | 110Ah |
| Nominal voltage | 25.6V |
| Volt range | 20V-29.2V |
| Charge time | Standard5.5h |
| Rapid 1.5h | |
| Charge method CC-CV | Standard 22A/29.2V |
| Rapid 100A/29.2V | |
| Max discharge current | Peak(10s) 1000A |
| Surge(60S) 400A | |
| Continous 100A | |
| Cycle life 0.5C, 23℃/73°F | 50% ＞7000 cycles |
| 100% ＞2000 cycles | |
| Operating temperature range | Charge 0°C~55°C/32°F~131°F |
| Discharge -20°C~60°C/-4°F~140°F | |
| Storage(1month) -20°C~45°C/-4°F~113°F | |
| Storage(6month) -10°C~35°C/14°F~95°F | |
| Water proof | IP67 |
Flammability rating | UL94-VO |
| Approx weight | 19.8kg /43.6lbs |
| Series & parallel connection | Supports 2-series connection for deepcycle use only; strictly forbid series for starting; parallel supported; ensure equal voltage before connection. |
| Length | Width | Width |
| 376mm | 194mm | 227mm |
| 14.8in | 7.63in | 8.94in |
| Balance | Current | 40mA |
| Activate volt | 3.55V/ cell | |
| High temperature protection(MOSFET) | Protection | 85°C/185°F |
| Release | 75°C/167°F | |
| High temperature protection(cell) | Protection | 65°C/149°F(charge) |
| 70°C/158°F(discharge) | ||
| Release | 55°C/131°F(charge) | |
| 60°C/140°F(discharge) | ||
| Low temperature protection(cell) | Protection | 0°C/32°F(charge) |
| -20°C/-4°F(discharge) | ||
| Release | 10°C/50°F(charge) | |
| -10°C/14°F(discharge) | ||
| Over-charge | Protection | 30.8V(3.85V/cell) |
| Release | 29.2V(3.65V/cell) | |
| Over-discharge | Protection | 18.4V(2.3V/cell) |
| Release | 20V(2.5V/cell) | |
| Short-circuit | Protection | 3800A |
| Release | Remove load for the short circuit protection to release |
| Length | Width | Width |
| 376mm | 194mm | 189mm |
| 14.8in | 7.63in | 8.94in |
Paired with the Bluetooth app, you can clearly see remaining time, usage status, and battery health at a glance — making it easy to plan every journey and every stop.
A single 12V battery (S110 or S200) can reliably run a 3 kW inverter.
A single 24V battery (S24110) can reliably run a 5 kW inverter.
Supports high-power camping appliances such as microwave ovens, coffee makers, kettles, and rice cookers smoothly.
Built-in BMS automatically protects against overcharge, over-discharge, short circuits, and overheating.
Actively balances cell voltages to extend battery life and ensure safety
Even in harsh conditions on the road, you can count on reliable power, worry-free.
IP67-rated protection.
Rugged ABS casing resists high temperatures and humidity
From chilly mornings to rainy nights in the mud, it stays rock-solid, safeguarding every camping trip.
With a cycle life of 2000+, over 5 times longer than standard lead-acid batteries, it delivers lower long-term costs and lasting durability — giving you confidence and peace of mind for every trip ahead.
Optional heating keeps your battery safe in cold weather. When temperatures drop, it automatically warms itself for smooth charging and startup. No more delays on chilly mornings — your RV is ready whenever you are.
Up to 80% lighter than comparable lead-acid batteries and nearly 50% more compact, freeing up precious space for your luggage, fridge, and camping gear. A lighter RV means more freedom, making every trip more relaxed and enjoyable.
