MC30 规格书
下载
Deep Connectivity · Intelligent Protection,
Making Every Voyage More Secure
| Stored energy | 128Wh | |
| Amp Hour(PdEq) | 30Ah, replace 15Ah-30Ah lead acid battery | |
| Nominal voltage | 12.8V | |
| Volt range | 10V-14.6V | |
| Charge time | Standard | 5.5h |
| Rapid | 1.5h | |
| Charge method CC-CV | Standard | 2A/14.4V |
| Rapid | 10A/14.4V | |
| Max discharge current | Crank | 600A |
| Continous | 10A | |
| Cycle life 0.5C, 23℃ | 10% | ＞1000 cycles |
| 100% | ＞300 cycles | |
| Operating temperature range | Charge | 0°C~45°C |
| Discharge | 0°C~45°C | |
| Storage(1month) | 0°C~35°C | |
| Storage(6month) | 10°C~25°C | |
| Water proof | IP67 | |
Flammability rating | UL94-VO | |
| Approx weight | 1.8kg | |
| Length | Width | Width |
| 146mm | 80mm | 144mm |
| Balance | Current | 130mA |
| Activate volt | 3.45V/ cell | |
| Over-charge | Protection | 15.8V(3.95V/cell) |
| Release | 14.4V(3.6V/cell) | |
| Time delay | ≤2S | |
| Over-discharge | Protection | 10.5V(2.5V/cell) |
| Release | 11.2V(2.8V/cell) | |
| Time delay | ≤3S | |
| Over current | Charge current | ≤45A |
| Discharge current | ≤45A | |
| Discharge over-current | 600A±5A | |
| Time delay | ≤5s | |
| High temperature protection(cell) | Protection | 75°C(charge) |
| Release | 50°C(charge) | |
| 60°C(discharge) | ||
| Low temperature protection(cell) | Protection | -5°C(charge) |
| -40°C(discharge) | ||
| Release | 0°C(charge) | |
| -30°C(discharge) | ||
| Jump On Start | Cut-off | <30% SOC& no vibration |
| Time delay | 60 Second | |
| Wake up | Jump on motorbike or charge battery | |
| Self-consumption | Working | ≤20mA |
| Sleep | ≤300uA | |
| Short-circuit | Protection | 960A |
| Release | Remove load for the short circuit protection to release | |
| Time delay | ≤500uS |
| Length | Width | Width |
| 146mm | 80mm | 144mm |
Delivers stable power for propulsion systems and high-load equipment
Maintains uninterrupted operation under extreme conditions
30kW Instantaneous Power Output，industry- leading power density and efficiency
