ESS-05 Datasheet
Download
Communication Protocol: CAN/RS485
| Maximum PV input power | 5000W |
| Maximum PV input current | 18A |
| Minimum PV input voltage | 40~450Vdc |
| Maximum PV input voltage | 500Vdc |
| PV start-up voltage | 40Vdc |
| MPPT voltage range | 60Vdc |
| Maximum PV input current | 100A |
| AC input voltage range | 90~280Vac |
| AC rated voltage | 208/220/230/240Vac |
| Rated output power | 3000W |
| Rated output voltage | 230Vac |
| AC output | Pure sine wave |
| Rated output frequency | 50/60HZ |
| Communication/Monitoring | RS485/CAN/WiFi(optional) |
| Warranty Period | Battery 5 years / Inverter 2 years |
| Battery type | LiFePO₄ |
| Nominal Voltage | 25.6V |
| Operating Voltage | 22~28.8V |
| Nominal Capacity | 324Ah |
| Nominal Energy | 8.2kWh |
| Dimension (W*D*H) | 440*250*790mm |
| Weight Approximate | ≈115kg |
| IP Rating | IP64 |
Integrates a 3KW inverter with an 8.2kWh (324Ah) LiFePO₄ battery. Its compact structure and plug-and-play functionality perfectly meet basic household electricity needs.
Features a high IP64 protection rating. The modular design combined with automotive-grade structural protection ensures high reliability and long-lasting durability even in harsh outdoor environments.
Supports remote firmware upgrades and protocol configuration via Bluetooth APP, allowing easy system maintenance through a mobile phone. It also offers multiple communication interfaces including RS485/CAN/WiFi (optional), making it convenient to integrate with smart home or energy management systems.
The inverter supports a wide MPPT input voltage range (40-450Vdc) and AC input voltage range (90-280Vac). The rated output voltage is flexibly adjustable among 208/220/230/240Vac, adapting to grid standards in different regions.
The 8.2kWh LiFePO₄ battery provides long-endurance support. The all-in-one body with a wheeled design makes it easy to move. Whether for homes, commercial sites, RVs, or camping, it delivers safe and stable power solutions.
Products undergo rigorous full-program aging tests with charge/discharge currents up to 100A, and are equipped with a self-developed patented multifunction tester to ensure stable battery performance. Backed by a 5-year battery warranty for added peace of mind.
