1kWh Solar Power Station-Solar Generator/ Solar Power Station-Shenzhen Ray-tech International Limited

1kWh Solar Power Station

ND324-300W

Communication Protocol: CAN/RS485

Inverter Tech Data

Battery Tech Data

Maximum PV input power	300W
Maximum PV input current	18A
Minimum PV input voltage	11~55Vdc
PV Array Max open circuit voltage	60Vdc
MPPT voltage range	11Vdc
Maximum PV input current	10A
AC input voltage range	100~264Vac
Rated output power	300W
Rated output voltage	230Vac
AC output	Sine wave
Rated output frequency	50/60HZ
Warranty Period	Battery 5 years / Inverter 2 years

Battery type	LiFePO₄
Nominal Voltage	3.2V
Nominal Energy	1kWh
Dimension (WDH)	320 × 220 × 142 mm
Weight Approximate	≈10.5kg
IP Rating	IP20

Features

Integrated 3-in-1 Design

Combines a battery, inverter, and MPPT functionality in one unit. It is completely installation-free and ready to use right out of the box (plug-and-play).

High Capacity & High Energy Density

Built-in 324000mAh/1036Wh LiFePO4 battery provides long-lasting power support for various devices, meeting the electricity needs of camping, emergency backup, or off-grid scenarios.

Ultra-long Lifespan, Safe & Durable

Utilizes LiFePO4 (Lithium Iron Phosphate) cells with superior thermal stability and cycle life. The battery supports up to 11,000 cycles, ensuring long-term cost-effectiveness and safety.

Multi-Mode Charging & Output Capability

Supports three input methods: solar panels (max 300W), AC mains (100-264VAC), and car charging. The output features a 230VAC@50Hz pure sine wave socket with a peak power of up to 500W, compatible with mainstream home appliances and electronic devices.

Lightweight & Portable

Weighing approximately 10.5kg with dimensions of 320×220×142mm, it is easy to carry by hand. Perfect for outdoor travel, RV living, or as a home backup power source.

Wide Operating Temperature Range

Charging temperature ranges from 0°C to 55°C, and the discharging range extends from -15°C to 55°C. This adaptability to various climatic conditions enhances the product's reliability in extreme environments.
