HZCI Series-(Liquid Cooling)

DSHCI-241PCS / DSHCI-261PCS

COMMERCIAL AND INDUSTRIAL ESS

Parameter

System Parameters

Model	DSHCI-241PCS	DSHCI-261PCS
DC Battery Parameters
Battery Rated Energy (KWh)	241	261
Battery Rated Voltage (V)	768	832
Battery Voltage Range (V)	672~ 864	728~ 936
Battery Type	LFP
Battery Energy (Ah)	314
Battery Life Cycle	6,000 Cycles (0.5C, 5%~95%DOD, 80%SOH)
Battery Standard Charge/Discharge Rate (C)	0.5
Battery Pack Series And Parallel	1P48Sx5	1P52Sx5
Module Cooling Method	Liquid Cooling
PCS Parameters
Optional PCS	125KWPCS
PCS Power (KW)	138
Maximum Current (A)	200
Maximum Efficiency	98.5%

Model	DSHCI-241PCS	DSHCI-261PCS
Energy Cycle Efficiency	≥ 90 %
Protection Level	IP55
Corrosion Resistance Level	C3 is the default, C4/C5 are optional
Fire Fighting	Aerosol/Perfluorohexanone (Optional)
Altitude	3000m (Derating Applies Over 2000m)
Relative Humidity	0~95% (Non-condensing)
Ambient Temperature	-20℃ ~ +50℃
Communications	4G/CAN/RS485
Dimensions (mm)	115514152340（±5MM）
Weight (T)	2350	2500
Warranty	5 years
Batteries, BMS, PCS converters are integrated into a single cabinet, supporting grid-connected/off-grid systems

Features

Integrated 3-in-1 Design

Combines a battery, inverter, and MPPT functionality in one unit. It is completely installation-free and ready to use right out of the box (plug-and-play).

High Capacity & High Energy Density

Built-in 324000mAh/1036Wh LiFePO4 battery provides long-lasting power support for various devices, meeting the electricity needs of camping, emergency backup, or off-grid scenarios.

Ultra-long Lifespan, Safe & Durable

Utilizes LiFePO4 (Lithium Iron Phosphate) cells with superior thermal stability and cycle life. The battery supports up to 11,000 cycles, ensuring long-term cost-effectiveness and safety.

Multi-Mode Charging & Output Capability

Supports three input methods: solar panels (max 300W), AC mains (100-264VAC), and car charging. The output features a 230VAC@50Hz pure sine wave socket with a peak power of up to 500W, compatible with mainstream home appliances and electronic devices.

Lightweight & Portable

Weighing approximately 10.5kg with dimensions of 320×220×142mm, it is easy to carry by hand. Perfect for outdoor travel, RV living, or as a home backup power source.

Wide Operating Temperature Range

Charging temperature ranges from 0°C to 55°C, and the discharging range extends from -15°C to 55°C. This adaptability to various climatic conditions enhances the product's reliability in extreme environments.
